Christie S+22K-J Projector (Roadster) (J-Series)

Christie S+22K-J Projector (Roadster) (J-Series)

The Christie S+22K-J projector is part of the new J-Series provided by Christie. This product is Ideal for boardrooms, broadcast sets, classrooms, conference rooms, rental/staging, training rooms and most other multi-media productions. The Christie S+22K-J projector is fitted with the broadest range of high quality lenses all with Intelligent Lens System (ILS™) capabilities. You can use existing stacking hardware, lenses, lamps, input cards and other Christie accessories for an example the portrait lens adapter with this new line of J-Series projectors.

This product creates visually compelling displays to paramount to your success. The S+22K-J projector produces higher brightness, Christie Twist™, image quality and flexibility standard. Additionally with an upgraded Xenon 3-chip DLP^® platform the features and functionality. This product is 3D upgradeable.

This projector couples the benefits of Xenon illumination – for the most natural colour accuracy and stability - with the next level of technology, performance and flexibility. The additional standard features, an expanded lens suite and world-renowned Christie warranties, service and support, ensure the Christie S+22K-J provides high performance and more lumens per watt in the smallest chassis in its class. With the Christie J-Series you can customise your model according to your needs. Each projector ships standard with the ILS lens mount, but if you prefer to use your existing inventory of CT lenses or require a yellow notch filter (YNF).

Benefits:

• SXGA+ resolution (1400 x 1050)
• 22,000 centre lumens
• Embedded Christie Twist™ for image warping and edge blending
• Variable contrast ratio of 1600-2000:1 full field | 650:1 ANSI for crisp, detailed images
• 3.0kW Xenon bubble lamp module
• Comprehensive colour Adjustment (CCA™)
• Dust-sealed engine
• Intelligent Lens System (ILS) for zoom, focus, horizontal and vertical offset
• Multiwindowing and screen processing (up to a 3x3 array)
• Set-up lights help users see menu displays in low-light environment
• Hybrid stack in
• User-replaceable lamp
• Built-in portrait capability
• Liquid cooling allows for operating temperatures up to 104°F (40°C
• 3D capable model available in the Mirage Series
• 3D upgradable
• CT lens mount (optional)
• Yellow notch filter (optional)
• AutoDesk^® Revit^® model

Lens Options:

• ILS HD Lens: Throw Ratios: 0.73:1 SX+/0.67:1 ILS HD Lens
• ILS HD Lens: Throw Ratios: 1.2:1 SX+/1.1:1
• ILS HD Lens: Throw Ratios: 1.25-1.6:1 SX+/1.16-1.49:1
• ILS HD Lens: Throw Ratios: 1.5-2.0:1 SX+/1.4-1.8:1
• ILS HD Lens: Throw Ratios: 2.0-2.8:1 SX+/1.8-2.6:1
• ILS HD Lens: Throw Ratios: 2.8-4.5:1 SX+/2.6-4.1:1
• ILS HD Lens: Throw Ratios: 4.5-7.1:1 SX+/4.1-6.9:1
• ILS HD Lens: Throw Ratios: 7.5-11.2:1 SX+/6.9-10.4:1

Specifications:

• Image: Brightness: 22,000 center (20,000 ANSI) lumens, Contrast: 1600-2000:1 Full Field | 650:1 ANSI, Uniformity: 90% brightness uniformity
• Display: Type: 3-chip 0.95" DMD, Native resolution: SXGA+ (1400 x 1050)
• Lamp: Type: 3.0kW Xenon bubble lamp module, Life: 750 hours typical lamp life
• Input: Standard: Analog, Dual link DVI, SD/HD-SDI, Video Decoder Optional: Analog, Dual link DVI, SD/HD-SDI, Video Decoder, Twin HDMI, Signals: HDTV formats VGA through to QXGA (2048 x 1536), Accepts all current HDTV/DTV formats, Multi-standard video decoder, Horizontal and vertical scaling, all inputs, Pixel clock: 165MHz, Scan rates: 15kHz ‐ 120kHz Horizontal, 23.97Hz ‐ 150Hz Vertical
• Control and networking: RS232 In/Out, RS422 In, Ethernet (10/100), USB Device, GPIO (RS232 9 Pin male connector), Built-in, backlit LCD keypad, Remote control (with optional wired XLR connection)
• Lens options: Fixed: ILS Lens 0.73:1 SX+ / 0.67:1 HD* - ILS Lens 1.2:1 SX+ / 1.1:1 HD Zoom: ILS Lens 1.25–1.6:1 SX+ / 1.16–1.49:1 HD** - ILS Lens 1.5–2.0:1 SX+ / 1.4–1.8:1 HD - ILS Lens 2.0–2.8:1 SX+ / 1.8–2.6:1 HD - ILS Lens 2.8–4.5:1 SX+ / 2.6–4.1:1 HD - ILS Lens 4.5–7.5:1 SX+ / 4.1–6.9:1 HD - ILS Lens 7.5–11.2:1 SX+ / 6.9–10.4:1 HD
• Offsets: +/- 100% Vertical, +/- 50% Horizontal, (* +/-23%V   +/- 13%H), (** +/-70%V   +/- 45%H)
• Standard Accessories: IR remote, Line cord
• Optional Accessories: 3.0kW Xenon lamp, 3.0kW Xenon lamp bare bulb kit, Bulb alignment tool, Analog input card, Dual link DVI input card, Video decoder input card, Dual SD/HD-SDI input card, Twin HDMI input card, DMX512 interface card, ILS lens adapter kit, Fog juice filters, Edge-blending kit\, Remote IR, sensor, 3D upgrade kit, Christie AutoStack™
• Enhanced feature sets: 3D Upgradeable, Embedded Christie Twist™, Embedded image tiling, Intelligent Lens System (ILS), Advanced block artifact reduction, ChristieNET™ Web interface, User-friendly, intuitive LCD keypad, Advanced Loop-Thru twin HDMI card, Lamp memory module, User replaceable lamps, Advanced, 10-bit processing, Automatic shut off and ECO mode, Dust-sealed light engine, SNMP (simple network management protocol), DHCP (dynamic host configuration protocol), Hybrid stack, Compatibility with legacy accessories
• Power requirements: Operating voltage: 200V AC to 240V AC @ 50/60Hz, Max current: 20A @4000V, Max power: 3200W, Dissipation: 13,650 BTU/hr
• Dimensions: Dimensions: (L x W x H): 32.0 x 24.5 x 16.5" (815 x 621 x 419mm), Shipping dimensions: (L x W x H): 41.0 x 32.5 x 29.5" (1041 x 825 x 749mm), Weight: 160 lb (72.5 kg) (without lens), Shipping weight: 200 lb (91 kg)
• Operating environment: Temp: 5 – 40°C (40 – 104°F), Humidity: 20 – 80% noncondensing
• Regulatory: Directives (EC) 2002/95/EC (RoHS); 2002/96/EC, (WEEE), Regulation (EC) No. 1907/2006 (REACH);,CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC, 60950-1; FCC, Part 15, Subpart B, Class A;, EN55022/CISPR22 Class A; EN55024 / CISPR24, Certifications marks: - cULus (Canada and US) - CE (EU) - CCC (China) - GoST-R (Russia) - KC (Korea) - PSE (Japan) - C-Tick (Australia & New Zealand) - South Africa
• Limited warranty: Three years parts and labour (including light engine)
