Christie DHD550-G Projector (G Series)

Christie DHD550-G Projector (G Series)

The Christie DHD550-G projector is a new released model part of the Christie G- Series. The Christie DHD550-G offers unsurpassed value and is a perfect fit for a variety of media applications. This projector provides trusted performance, reliability and exceptional image quality into one unit. This product additionally provides the best of attributes with colour matching capabilities, image blending and warping and with the single lamp design, this lowers the total cost of ownership by reducing maintenance and energy cost. The DHD550-G integrated new media technologies the Christie DHD550-G has a DLP technology combined with the body of the projector.The DHD550-G has three compatible lens options. This series ships standard with a six-segment colour wheel for maximum brightness. This projector has optional accessories and upgrades available. Additionally this projector has 24/7 use capabilities. The Christie G Series provides a powerful package of high brightness with the integrated 5550 ANSI lumens, features and value. Producing exceptional images, the G Series also offers installation flexibility, ease of use and industry-leading reliability.

The Christie DHD550-G has an intergrated single lamp. The use of a signle lamp increases the lamp life therefore saving you cost in maintenance. The projector has a 1-chip DLP technology additionally providing excellent image quality and reliability. The DHD550-G provides a full suite of compatible lens options, input options and eco-freindly features that lower the total cost of ownership. Additional warranty services can be purchased with this projector.With this projector there is intergrated dynamic contrast, which enhances images by increasing the contrast ratio to 5000:1. An optional wireless module is available to purcase so there can be device flexibility and easy presentation set-up. Nevertheless with this projector there is a built-in colour matching for a more uniform image in a multiple projector configuration.

DLP (Digital Light Processing)
DLP (Digital Light Processing) is a display technology used in AV Projector products. The technology inside is often referred to as DMD (Digital Micro-Mirrors). It consists of an array of mirrors where each mirror represents a pixel element. For example, a high-definition DLP projector or rear projector with 1920 x 1080 pixel resolution would have over 2 million tiny mirrors. Each mirror is attached to an electronically driven hinge that controls the amount of coloured light that is reflected from the screen surface.

Benefits:

• proven DLP® technology
• excellent image quality
• reliability
• 5,500 centre lumens – the brightest platform in its category
• optional wireless connectivity
• energy-saving features
• low maintenance costs
• many standard features
• the best Warranty and support in the industry
• single-lamp design
• 1-chip DLP technology for excellent image quality and reliability
• filter-free and dust-sealed for low maintenance and costs
• Dynamic Contrast, which enhances images by increasing the contrast ratio to 5000:1
• an optional wireless module for device flexibility and easy presentation set-up
• built-in colour matching for a more uniform image in a multiple projector configuration
• blending and warping capabilities for curved surfaces
• 24/7 use capability
• eco-friendly features

Lens Options:

• Short Zoom Lens: Throw: 0.95 - 1.22
• Medium Zoom Lens: Throw Ratio: 1.22 - 1.52:1
• Long Zoom Lens: Throw Ratio: 1.52 - 2.89

Specifications:

• Brightness: 5,500 lumens
• Contrast: 5000:1
• Technology: 1-chip DLP
• Resolution: 1920 x 1080 HD
• Lamp: 370W P-VIP
• Lamp Life: HDTV formats VGA through to WUXGA (1920 x 1200)
• Input signal compatibility: Horizontal and vertical scaling while maintaining aspect ratio, all inputs
• Pixel clock: 162MHz
• Scan rates: Horizontal: 15kHz to 100kHz - Vertical: 24kHz to 85kHz
• Inputs, control and networking: HDMI x 1, DVI-D x 1 (digital only), DisplayPort x 1, HD15 x 1, Composite video x 1 (RCA), S-Video x 1 (mini DIN), Component video (RCA), USB x 1 (type B mini) - display over USB, USB x 1 (type A) - image viewer or WiFi dongle (optional), RJ45 x 1, RS232 in, Ethernet (10/100) RJ45 with ChristieNET connectivity, Build-in backlit keypad, Wired remote control (3.5mm stereo) - wire not included
• Optical system: Motorised zoom, focus and lens shift and mechanical light shutter
• Zoom Lenses: 0.95-1.22:1 (HD) zoom lens, 1.22-1.52:1 (HD) zoom lens, 1.52-2.89:1 (HD) zoom lens
• Offsets: Vertical: +/-120% (+/- 648 pixels), Horizontal: +/-20% (+/-192pixels)
• Standard accessories: IR remote w/ wired remote jack (wire not included), AC line cord for projector head, User manual
• Optional accessories: Wireless dongle, Warp module, Cable cover, Ceiling mount, Ceiling mount extension rod
• Power requirements: Operating voltage: 100V AC to 240V AC @ 50/60Hz, Operating current: 6A max, Power consumption: 510W max, 405W eco mode, Dissipation: 1740 BTU/hr max, 1382 BTU/hr eco mode
• Dimensions and weight: Size: (L x W x H): 15.28 x 17.13 x 8.15” (388 x 435 x 207 mm) excluding feet, Shipping size: 19.49 x 23.03 x 16.14" (495 x 585 x 410mm), Weight: 33.1lb (15kg), Shipping Weight: 41.2lb (18.7kg)
• Operating environment: Temperature: 40 – 95°F (5 – 35°C), Humidity: 0 – 90% non-condensing
• Regulatory approvals: UL/CSA/IEC 60950-1, FCC Class A, CE, CCC, KC, Gost-R, PSE, C-tick, and South Africa, This product conforms to all relevant European directives, standards, safety, health and environmental concerns, RoHS, REACH, WEEE
• Limited warranty: 3 years parts and labour (including light engine), Contact an authorised Christie representative for full details of our limited warranty
