Christie DHD675-E Projector (E Series)

Christie DHD675-E Projector (E Series)

The Christie DHD675-E projector is a new released model part of the Christie E- Series. This projector provides trusted performance, reliability and exceptional image quality. With integrated new media technologies the Christie DHD675-E has a DLP technology combined with the body of the projector. This product additionally provides the best of attributes with colour matching capabilities for the best viewing image with every use, image blending and warping so the projector can provide crisp detailed images, energy-saving features so the cost of maintaining the projector can be kept minimal, additionally  this projector has 24/7 use capabilities. The Christie E Series provides a powerful package of high brightness with the integrated 5850 ANSI lumens, features and value. Producing exceptional images, the E Series also offers installation flexibility, ease of use and industry-leading reliability.

The dual-lamp design offers the choice to use the projector in dual-lamp or single-lamp mode. Dual-lamp mode maximizes brightness and is great for redundancy. Single lamp mode increases the lamp life. The projector has a 1-chip DLP technology additionally providing excellent image quality and reliability. The Christie DHD675-E projector has optional accessories and upgrades available for an example wireless module makes the projector more flexible to use and easy to set up. The DHD675-E provides a full suite of compatible lens options, input options and 360 degree projection give you the flexibility to pick what works best for your presentation. The Christie DHD675-E is ideal for fixed install applications. The optional stacking, blending and warping capabilities also make it a great option for staging applications. This projector comes with a number of eco-friendly features that lower the total cost of ownership. This projector is ideal for small auditoriums, boardrooms, classrooms and museums.

DLP (Digital Light Processing)

DLP (Digital Light Processing) is a display technology used in AV Projector products. The technology inside is often referred to as DMD (Digital Micro-Mirrors). It consists of an array of mirrors where each mirror represents a pixel element. For example, a high-definition DLP projector or rear projector with 1920 x 1080 pixel resolution would have over 2 million tiny mirrors. Each mirror is attached to an electronically driven hinge that controls the amount of coloured light that is reflected from the screen surface.

 Benefits:

• DLP® technology
• colour matching
• image blending and warping
• projector stacking capabilities
• energy-saving features
• low maintenance costs
• industry-leading warranties and support.
• dual-lamp design offers the choice to use the projector in dual-lamp  or single-lamp mode. Dual-lamp mode maximizes brightness and is great for redundancy. Single lamp mode increases the lamp life.
• 1-chip DLP technology provides excellent image quality and reliability
• 24/7 use capability
• Dynamic Contrast enhances images by increasing the contrast ratio to 5000:1
• an optional wireless module makes the projector more flexible to use and easy to set up.

Lens Options:

• Fixed Short Lens: Throw: 0.8:1
• Zoom Lens: Throw: 1.2-1.5:1
• Standard Zoom Lens: Throw: 1.5-2.0:1
• Long Zoom Lens: Throw: 2.0-4.0:1
• Super Long Zoom Lens: Throw: 4.0-7.0:1

Specifications:

• Brightness: 6,450 centre (5850 ANSI) lumens
• Contrast: Up to 5000:1
• Technology: 1-chip DLP
• Resolution: HD 1920 x 1080
• Lamp: Dual 330W P-VIP
• Lamp Life: 1800 hrs minimum @ 330W,  2500 hrs typical @ 280W
• Input signal compatibility: HDTV formats VGA through to WUXGA (1920 x 1200), Horizontal and vertical scaling while maintaining aspect ratio, all inputs
• Pixel clock: 162MHz
• Scan rates: Horizontal: 15kHz to 100kHz - Vertical: 24kHz to 85kHz
• Inputs, control and networking: HDMI x 2, Display port x 1, RGBHV (5 BNC), HD15 x 1, Composite video x 1 (RCA), S-Video x 1 (mini DIN), Component video (RCA), USB x 1 (type B mini) - display over USB, USB x 1 (type A) - image viewer or WiFi dongle (optional), RJ45 x 1, RS232 in, Ethernet (10/100) RJ45 with ChristieNET connectivity, Build-in backlit keypad, Wired remote control (3.5mm stereo) - wire not included
• Optical system: Motorised zoom, focus and lens shift and mechanical light shutter
• Fixed lens: 0.8:1
• Zoom Lenses: 1.2-1.5:1 zoom lens, 1.5-2.0:1 zoom lens, 2.0-4.0:1 zoom lens, 4.0-7.0:1 zoom lens
• Offsets: Vertical: +134% (+ 720 pixels)/ - 40% (- 216 pixels) - Horizontal: +/-20% (+/-192pixels)
• Standard accessories: Brightness colour wheel, IR remote w/ wired remote jack (wire not included), AC line cord, HDMI-DVI cable with locking HDMI connector, User manual
• Optional accessories:  Wireless dongle, Warp module, Rich colour wheel (RGBCMY), Stacking frame (must be used with Stacker Adapter Plate), Stacker plate, Ceiling mount, Ceiling mount extension rod
• Power requirements: Operating voltage: 100V AC to 240V AC @ 50/60Hz, Operating current: 9.2A max at 100V, Power consumption: 855W max (dual lamp 330W), 735W eco mode (dual lamp 280W), Dissipation: 2917 BTU/hr max, 2508 BTU/hr eco mode
• Dimensions and weight:  Size: (L x W x H): 20.9 x 18.0 x 8.5” (532 x 456 x 215 mm) excluding feet, Shipping size: 23.3 x 38.0 x 15.4" (591 x 965 x 390mm), Weight: 43 lb (19.5 kg), Shipping Weight: 58 lb (26.3 kg)
• Operating environment: Temperature: 40 – 95°F (5 – 35°C), Humidity: 0 – 80% non-condensing
• Regulatory approvals: UL/CSA/IEC 60950-1, FCC Class A, CE, CCC, KC, Gost-R, PSE, C-tick, and South Africa, This product conforms to all relevant European directives, standards, safety, health and environmental concerns, RoHS, REACH, WEEE
• Limited warranty: 3 years parts and labour (including light engine), Contact an authorised Christie representative for full details of our limited warranty
